Suitable for the storage of biological samples such as viruses, blood cells, bacteria and tissue, as well as electronics and other special materials.
The freezer combines frequency conversion compressors, hydrocarbon refrigerants (HC) and dual refrigeration system technology to deliver optimal sample security, energy-efficiency, and sustainability.
The product is used within hospitals, disease control, life science and medical research, bioengineering, pharma and other enterprize laboratories.
Product Features
Large loading capacity
Maximum Capacity: 600 boxes (2 inch boxes with 10*10 configuration) 60,000 samples can be stored
Optional IoT System
The optional IoT monitors the operating status of the equipment in real time. Equipped with multiple alarm functions and a self-diagnostics system to identify and warns users to ensure sample safety
World-leading Energy Saving Refrigeration Technology
Intelligent frequency conversion technology and HC refrigeration system delivers a 50% reduction in energy usage when compared to traditional HFC refrigeration systems
Environmental Protection
Environmentally friendly hydrocarbon refrigerant and foam material LBA
Dual refrigeration system, double safety and optimal reliability
Double independent hydrocarbon refrigeration system design, each system can maintain -80ºC ensuring the safety of stored samples
Low Noise Design
Optimised systems and noise-reducing cabinet design lower noise out to 53dB for a quieter working experience
Adjustable Sample Loading Tray (Optional)
The adjustable height sample load tray provides users with a convenient place to hold samples while opening and accessing storage compartments
Intelligent Control
10.1-inch high-performance touch screen, sensitive touch operation. Users can check the real-time operating status via IoT
Specifications
| Model |
Capacity (L/Cu.Ft) |
Temperature Range (ºC) |
Power Supply (V/Hz) |
Exterior Dimensions (W*D*H)(mm) |
Shelves/ Inner Doors |
Certification |
| DW-86L728BPST |
728/25.7 |
-40~-86 |
100~230/50/60Hz |
1046*998*1980 |
3/4 |
CE/UL/Energy Star |
| DW-86L578BPST |
578/20.4 |
-40~-86 |
100~230/50/60Hz |
895*998*1980 |
3/4 |
CE/UL/Energy Star |
| DW-86L828BPST |
828/29.2 |
-40~-86 |
100~230/50/60Hz |
1145*998*1980 |
3/4 |
CE/UL/Energy Star |
