Mainly intended for the quick-frozen treatment of blood plasma or biological samples to a core below -30°C within 1 hour in blood stations or medical institutions.
Product Features
Flexible set up
The storage temperature, freezing time, and defrosting time can be flexibly set as required
Electric lifting system
Height control is more accurate and quieter than pneumatic lifting system
Simple operation
All pre-cooling, freezing, defrosting procedures are controlled by PLC control module, simple operation, avoid wrong operation, ensure plasma safety
Password protection
Parameter setting is password protected to ensure plasma safety
Rapid-freezing tray design
Rapid-freezing tray design, not only to improve the efficiency of plasma rapid-freezing, but also easy to save labor
Friendly interface
Friendly interface display design, clearer temperature observation
Low rapid-freezing temperature
Rapid-freezing temperature can be reduced to -60ºC, superior performance
Data is printable and the information traceable
Plasma storage data and corresponding curves can be exported via USB, which is convenient for information traceability
Efficient core components, energy saving
High efficiency compressor and dual-cooling system, better performance; Hydrocarbon refrigerant, energy saving and environmental protection
click here to download brochure
click here to download flyer
click here to download flyer
click here to download flyer
Specifications
| Model |
Rapid-cooling type |
Power Supply(V/Hz) |
External Dimension(mm) |
Weight(kg) |
| XSD-24FL |
Plate contact quick-freezing |
3N 380-50/60 |
1455*915*1575 |
480 |
| XSD-24WFL |
Plate contact quick-freezing |
3N 400V/50HZ/60HZ |
1455*915*1465/1340*760*1640 |
320/360 |
| XSD-48WFL |
Plate contact quick-freezing |
3N 400V/50HZ/60HZ |
2040*880*1895/1340*760*1640 |
640/360 |
